Premium Perf Frame Kit | Standard & Palm Panels

The aluminium framing system required to complete your Premium Perf standard or palm design panel installation. The two part frame rail design allows for hidden screw fixing of the perf sheet to the frame, with snap in covers that conceal the fixings for a clean, professional finish.

This frame kit supports two installation methods. With shrouds and brackets, or with U channel fixing direct to posts. The flat top pool fence brackets we stock are compatible with this frame kit and are available separately in our hardware range.

Specifications:

• Material: Marine grade aluminium
• Finish: Akzo Nobel powder coat - black or monument texture
• Includes 2 x horizontal top and bottom rails, 2147mm long
• Includes 2 x vertical side rails, 1149mm long
• Rail profile: 38mm x 25mm, matches standard aluminium pool fence panels
• Snap in covers for hidden screw fixing
• Frame kit is height and width adjustable, simply cut to size
• Suits standard and palm design panels only
• Not suitable for transitional panels

Installation methods:

• Method 1 - Shrouds and brackets: standard panel height 1200mm, suits daylight opening width of 2150mm between posts
• Method 2 - U channel fixing: standard panel height 1200mm, suits daylight opening width of 2012mm between posts

Before ordering:

Frame kit suits standard and palm design panels only. Transitional panels require the transitional frame kit sold separately.

Compatible flat top brackets and U channels available separately in our hardware range. Panels sold separately.

Not sure what you need? Send us a message with your measurements and we’ll help you work out quantities before you order.
